Caldera Elation 2005/2006/2007/2008 Caldera Elation
This Blog was posted on May 11, 2013 by HTSS.
2005-2008 Caldera ELation Model ELM is indicated by the letter in the serial number. for example.
Serial Number ELM-3G2015 the serial number would read ELM is model 3 third quarter G year(2005) and 2015 is the unit number made.
Serial Number ELM-3H2015 the serial number would read ELM is model 3 third quarter H year(2006) and 2015 is the unit number made.
Serial Number ELM-3J2015 the serial number would read ELM is model 3 third quarter J year(2007) and 2015 is the unit number made.
Serial Number ELM-3K2015 the serial number would read ELM is model 3 third quarter K year(2008) and 2015 is the unit number made.
|
Specifications
|
|
|
Dimensions:
|
7'7" x 7'7" x 38"
|
|
Water Capacity:
|
500 gallons
|
|
Weight:
|
Dry: 930 lbs. Filled: 6,135 lbs. |
|
Electrical Req:
|
230v, 50 or 30 amp single phase GFCI protected circuit
|
|
Ozonator:
|
Monarch CD Ozone Generator
|
|
Filter: (1 ea.)
|
73531- 15 inch.75 sq.ft. filter |
Below is a list of common replacement items. Be sure to see specifications page for parts diagrams or related Videos
