2005/2006/2007/2008/2009/2010 Tiger River Bengal Model MM
Model MM has a Waterfall, a larger jet pump and runs only 220V)
Serial Number MM-3G2015 the serial number would read MM is model 3 third quarter G year(2005) and 2015 is the unit number made.
Serial Number MM-3H2015 the serial number would read MM is model 3 third quarter H year(2006) and 2015 is the unit number made.
Serial Number MM-3J2015 the serial number would read MM is model 3 third quarter J year(2007) and 2015 is the unit number made.
Serial Number MM-3K2015 the serial number would read MM is model 3 third quarter K year(2008) and 2015 is the unit number made.
Serial Number MM-3L2015 the serial number would read MM is model 3 third quarter J year(2009) and 2015 is the unit number made.
Serial Number M-3M2015 the serial number would read MM is model 3 third quarter K year(2010) and 2015 is the unit number made.
(2009 and 2010 Models use heater relay board 76071 and use control box 76082)
2009 and 2010 Models look like picture below
|
Specifications
|
|
|
Dimensions:
|
7’2 ½" x 6'7" x 33" (2.2 m x 2.01 m x 0.84 m) |
|
Water Capacity:
|
330 gallons (1249 liters)
|
|
Weight:
|
490 lbs. (222 kg) dry 4,005 lbs. (1817 kg) filled |
|
Electrical Req:
|
115v, 20amp circuit 230v, 50amp circuit |
|
Ozonator:
|
Fresh Water II
|
|
Filter:
|
71827 (Qty =1) |
Below is a list of common replacement items. Be sure to see specifications page for parts diagrams or related Videos
