36220 Diverter Bezel Grey

$3.61
In stock
SKU
36220
Add to Wish List
In stock

Add to wishlist
36220 Diverter Bezel Grey
36220 Diverter Bezel Grey

Grey Diverter Bezel for 1996-1997 Hot Spring Spa Models



The diverter valve is located on the outlet side of the jet pump and allows for the diversion of water to the desired jet modes. The diverter valve has only two positions that are 180 degrees from each other,



Removal
  1. Remove the lever by lifting straight up. The lever is held on the diverter shaft by friction.
  2. Remove the bezel caps and screws located on either side of the diverter shaft.
  3. Remove the bezel.
  4. Using the snap ring tool, remove the snap ring.
  5. Slide the center core out of the diverter. If this is difficult, pliers can be used to gently pull the core out. Caution: Do not damage the shaft where the lever is attached.
  6. Note the location of the core plug and o-rings.

DIVERTER VALVE INSTALLATION

  1. Using silicone grease, grease and position the core plug o-rings. Place the two small o-rings in the shaft pocket located on the bottom side of the core plug. The larger o-ring is placed around the perimeter of the core plug (reference the original core plug for locations).
  2. Slide the core plug with the o-rings in position over the core shaft.
  3. Grease the outside of the core with silicone grease.
  4. Slide the core into the body. Be sure the core is seated properly and the o-ring has not become damaged.
  5. Press down on the core plug to be sure the core is completely seated.
  6. Install the snap ring using the snap ring tool. Caution: Ensure that the snap ring is fully positioned. Injury may result if the snap ring is not positioned properly when the jets are activated.
  7. Replace the bezel and lever at the same time. It can be difficult to install the lever when the bezel has been tightened down. Make sure to fully seat the lever as it fits very tightly onto the core shaft.
  8. Reinstall the bezel screws and caps.



Specifications

Item Description Part #
1 Body, Diverter Valve (2 Position) 37704
2 Nut, Diverter Valve 75117
3 O-ring 34319
4 Collar, Diverter Valve 75116
5  Diverter Valve Kit  70849
6a  Diverter Bezel 2IN 94
34310
6b Diverter Bezel 2IN Grey 36220
7   Snap Ring, Diverter Valve 34350
8  Diverter Valve Kit Screw 8-16x1/2  33850
9a  Air Control And Diverter Valve Screw Cap White 33833
9b Air Control And Diverter Valve Cap Gray Quarite 36224
10 Diverter Valve Lever White  34311
