36505 Air Valve Bezel, Grey

$2.09
In stock
SKU
36505
Add to Wish List
In stock

Add to wishlist
36505 Air Valve Bezel, Grey
36505 Air Valve Bezel, Grey

Air Valve Bezel in Grey is for 1993-2003 Hot Spring models, and 1999-2003 Tiger River models.

Air control valves, located on the spa’s bartop, allow the spa user to control/adjust the amount of air that is supplied to specific hydrotherapy jets in the spa. The amount of air is controlled/adjusted by a turn of the air lever. The more air, the stronger the jet pressure feels.

The force of the water pressure rushing through the individual jets in a Venturi effect inducts the air through the air valves. The air check valves located in the equipment compartment under the bartop provide the air intake for the air valves.

The air control valves consist of a cap, lever, bezel, retainer, piston and valve body.



Removal
  1. Gently pry the screw cap upward and remove the Phillips head screw.
  2. Remove the lever.
  3. Remove the bezel.
  4. Using the Spanner tool, remove the air valve retainer.
  5. Pull the air valve piston upward and out of the valve body. If the air valve piston is difficult to remove, place a cloth over the spline shaft and use pliers to gently pull the piston out of the valve body.
    Caution: Do not damage the spline on the piston shaft.

AIR CONTROL VALVE INSTALLATION

  1. Using silicone grease, grease the inside of the valve body.
  2. Grease (silicone grease) the three valve kit o-rings.
  3. Install the two equal sized o-rings into the valve piston o-ring grooves. The grooves are located at the top and bottom of the piston barrel.
  4. Apply a second coating of silicone grease on the outside of the o-rings.
  5. Install the remaining o-ring into the o-ring retainer located around the air opening in the barrel of the piston. This is performed simultaneously by locating the o-ring in position and sliding the piston into the valve body.
    Important: Ensure the o-ring is properly seated as the piston is being slid into the valve body.
  6. Using the air valve lever, place the lever onto the spline shaft and press downward to seat the piston into the valve body. Once the piston is seated, turn the piston back and forth to check proper actuation. Once actuation is verified, turn the piston all the way clockwise until stopped.
  7. Use the Spanner tool to install and tighten the piston retainer ring.
  8. Install the bezel.
  9. Install the lever in the clockwise most position. Check to make sure the lever travels the full length of the bezel opening.
  10. Install the lever screw and screw cap.
Specifications



Item Description Part #
1 Air Control Valve Gasket 33830
2 Air Control Valve Body 33838
3 Air Control Valve O-ring 33831
4 Air Control Valve O-ring 33832
5 Air Control Valve Stopper 33836
6a Bezel, Air Valve 1997 36503
6b Bezel Air Valve Grey 1997 36505
6c Bezel, Air Valve, Taupe 39878
7a Air Control Valve Lever White 33834
7b Air Control Valve Lever Gray 36209
7c Air Control Valve Lever Taupe 39869
8 Diverter Valve Kit Screw 8-16x1/2 33850
9a Air Control Valve Cap Seafoam Green 37496
9b Air Control Valve Cap Darkteal Quarite 37568
9c Air Control Valve Cap Taupe 39870
10 Screw N/A
11 Air Control Valve Piston Wth O-ring 70442
