72316 Euphoria Jet Without Without Escutcheon

$40.71
In stock
SKU
72316
Add to Wish List
In stock

Add to wishlist
72316 Euphoria Jet Without Without Escutcheon
72316 Euphoria Jet Without Without Escutcheon

The Euphoria is a powerful jet that combines water pressure and air to provide a substantial stream. The Euporia is located in the footwell of the spa to provide a massage to the feet and calves.

For 2001- Current Caldera Spas

Replacement Instructions

. Before starting the replacement instructions have the spa drained with the foam dug out exposing the rear wall fitting retaining ring that holds the jet in place.

  • Turn the retaining ring counterclockwise to remove.
  • Remove the nozzle and seat ring.
  • Remove the front wallfitting.
  • Access the rear portion of the shell. NOTE: Removal of wood and foam may still be required.
  • Remove the rear wallfitting assembly from the spa's plumbing and once separated pull front wall fitting through the water side.
  • To replace the jetstream, reverse the steps.



Note:
Silicon is used to seal the jets front and rear wall fitting to spa.



Specifications



Item Description Part #
1 Euphoria Jet 72316
* Euphoria Jet W/Escutcheon 73851
